Case 621G - Right-Hand Side Controls; Overview

To Next Page

To Previous Page

3-CONTROLSANDINSTRUMENTS

Right-handsidecontrols

Overview

LEIL17WHL2029FB1

1.Multifunctionkeypad6.USBandAUXports

2.Ignitionswitch7.Poweroutletsocket12V

3.Controllever(joystick)

8.Horn

4.Armpad9.Armpadrelease

5.Cupholder

Theright-handsideconsoleallowstheoperatortomakeadjustmentstomachineoperationsandfunctions.

3-20
