Case 621G - Parking Brake

3-CONTROLSANDINSTRUMENTS
Parkingbrake
WARNING
Run-overhazard!
Applytheparkingbrakebeforeleavingthecab.
Failuretocomplycouldresultindeathorseriousinjury.
W1390A
Parkingbrakebutton
Makesurethemachinehascometoa
completestopbeforeapplyingtheparking
brake.
Theparkingbrakebuttonengagestheparkingbrakeon
thetransmissionoutputshaft.
NOTICE:theparkingbrakeisaspringapplied,hydraulic
releasedbrakewhichisappliedtothedriveshaft.The
parkingbrakewilleffectivelyholdthemachineinplace
whenusedcorrectly.
LEIL16WHL1125AA1
Engagingtheparkingbrake
Toengagetheparkingbrake,movethetransmissioncon-
trollevertoNEUTRAL(N),stopthemachineandpush
theparkingbrakebutton.Theparkingbrakewillautomat-
icallyengagewhenthemachineisshutoff.
NOTICE:afailureintheoperatingprocedureorafailure
intheelectricalorhydraulicfunctioncanresultinabrupt
engagementoftheparkingbrake.Alwayswearyourseat
belt.
NOTICE:applytheparkingbrakepriortoleavingthecab
and/orparkingthemachineonslopes.
Parkingbrakerelease
NOTE:theservicebrakemustbeatoperatingpressure
beforetheparkingbrakecanbereleasedtomovethema-
chine.Thebrakepressureindicatorlamponmultifunc-
tiondisplaymustnotbeilluminatedwhendisengagingthe
parkingbrake.Attemptingtomovethemachinepriorto
theservicebrakepressuresbeingsufcientcausinglow
operatingpressurecanresultinprematureparkingbrake
padwear.
LEIL16WHL1570AB2
3-35
