Case 621G - Joystick Steering

3-CONTROLSANDINSTRUMENTS
Joysticksteering
WARNING
Drivinghazard!
Ifthehydraulicpilotsaredisengaged,thejoysticksteeringremainsactive.Alwaysdisengagethe
joysticksteeringwhennotinuse.
Failuretocomplycouldresultindeathorseriousinjury.
W0449A
WARNING
Drivinghazard!LimittheusetheJoystickSteeringSystem(JSS)atspeedsabove20km/h(12.4mph).
UsetheJoystickSteeringSystem(JSS)toassistworkcycleoperations.Foroptimumcontrol,always
usetheprimarysteeringwheelwhenyouoperateathigherspeeds.DonotuseJSSforlongtravelat
highspeeds.WhenyouenableJSS,themaximummachinespeedis30km/h(18.6mph).
Failuretocomplycouldresultindeathorseriousinjury.
W1514A
WARNING
Drivinghazard!
Alwaysusetheprimarysteeringwhentravelingonapublicroadorhighway.Theleftarmrestmustbe
raisedandinalockedpositionduringtravel.Donotusejoysticksteeringwhentravelingonapublic
roadorhighway.
Failuretocomplycouldresultindeathorseriousinjury.
W0451A
Joysticksteering(optional)
Thejoysticksteering(JSS)allowstheoperatortosteerus-
ingahandcontrolslocatedontheleft-handoperatorseat
armrest.Thejoysticksteeringallowsforsteeringmove-
mentattheoperator’sngertips.
Usethesecontrolsinshortcycle,repetitive,highproduc-
tionloadandcarryoperationstoreduceoperatorfatigue
andincreaseoperatingefciency.
Thesystemissetupsothatthesteeringwheelisalways
usable(italwayshaspriority).
TheJSSisnotdeactivatedwithsteeringwheeluse.When
thesteeringwheelisused,theJSSnolongerhascontrol.
Assoonasthesteeringwheelisnolongerbeingturned,
theoperatorisabletogobacktousingthejoystickwithout
havingtoreactivateit.
LEIL16WHL1403AB1
1.Joysticksteering(JSS)controllever
2.Joysticksteering(JSS)switch
SeeChapter6-“WORKINGOPERATIONS”forfurther
information.
3-17
