Case 621G - Page 76

To Next Page

To Previous Page

3-CONTROLSANDINSTRUMENTS

Right-handbrakepedal(Optional)

Anadditionalrightbrakepedalcanbeadded,allowing

boththeleftandrightpedaltobelockedtogether.Braking

canbeperformedfromeitherpedal.

LEIL16WHL1270AB4

3-16
