4-OPERATINGINSTRUCTIONS

Operatingthemachine

Startingandstoppingtheloader

1.Removethetransport/servicelinkfromthelockedpo-

sition,andsecurethetransport/servicelinkinthework

(unlocked)position.

LEIL16WHL0047AA1

2.PlacethetimeddisconnectswitchintotheONposition.

RCPH10WHL106AAH2

3.Sitintheoperator’sseatwiththeseatbeltcorrectly

fastened.Makesureyoucanpushthefootpedals

completelydownwithyourbackagainsttheseat

cushion.ConrmthattheparkingbrakebuttonisON

(brakeengaged).Keepallnon-authorizedpersonnel

clearofthearea.

LEIL16WHL1125AA3

4.ThetransmissioncontrollevermustbeinNEUTRAL.

LEIL16WHL1469AB4

4-7
