Case 621G - Steering Column

3-CONTROLSANDINSTRUMENTS
Steeringcolumn
WARNING
Hazardtobystanders!
Alwayssoundthehornbeforestartingthemachine.Makesuretheworkareaisclearofotherpersons,
domesticanimals,tools,etc.beforeyouoperatethemachine.Neverallowanyoneintheworkarea
duringmachineoperation.
Failuretocomplycouldresultindeathorseriousinjury.
W0304A
Right-handmultifunctionlever
1.Horn
Pushthehornbuttonintoactuatethehorn.
2.Turnsignallever
Pushthecontrolleveruptosignalaleft
turn.Pulltheleverdowntosignalaright
turn.Movethelevermanuallytothecenter
positiontostopthesignals.
3.Highbeamheadlightsandashing
Pullthemultifunctionlevertoturnon
thehighbeamheadlights.Pushthe
multifunctionleverforashing.
4.Drivinglightwheel
Rotatethewheel(4)tosetoneofthethree
positions:
0–LightsOFF
1–Marker/positionlights
2–Lowbeamheadlights
5.Frontwiper/washerwheel
Rotatethewheel(5)tosetoneofthefour
positions:
0-OFFposition.
I-ONposition–Rotateclockwisethewheel
(5)totherstpositiontoactivatethefront
wiper.
L-INTERMITTENT-Rotateclockwisethe
wheel(5)tothesecondpositiontoactivate
thefrontwiperattheintermittentspeed.
H-CONTINUOUSLY-Rotateclockwise
thewheel(5)tothethirdposition.Thefront
wiperrunscontinuously.
WASH-Rotatecounterclockwiseandhold
thewheel(5)forwasheruid.
6.Frontwiperspeedwheel
Rotatethewheel(6)toadjustandsetthe
frontwiperintermittentspeed.Thereare
sixsettingsforthefrontwiperintermittent
speed.
