7-MAINTENANCE

Cabairlter-Cleaning

WARNING

Eyeinjuryhazard!

Wearfullcoveragesafetyglasseswithsidepanelswhenusingcompressedair.

Failuretocomplycouldresultindeathorseriousinjury.

W1531A

Cleanthecabairlterevery250hours.

NOTE:itisrecommendedtoperformthecleaningofcabairpre-lterandlteratthesametime.

1.Turnthelatch(1)toopentheright-handdoor(2).

LEIL16WHL1352AA1

2.Unhookthethreeclipssecuringtheltergridassembly.

LEIL15WHL0637AA2

3.Removetheltergridassembly(1)fromthelterhous-

ing(2).

LEIL17WHL1653AB3

7-70
