2-SAFETYINFORMATION

Handsignals

Whenoperatingthemachine,neverattempttocarryouttaskscallingfornecontrolortoworkinareaswherevisibility

ispoororimpairedwithoutseekingtheassistanceofasignalperson.Makeperfectlysurethatyouandthesignal

personunderstandthesignalstobeused.

Starttheengine

LEEN11T0005AA1

Stoptheengine

LEEN11T0006AA2

Cometome

Wavehandsbackandforth(palmsinward).

LEEN11T0007AA3

2-17
