Case 621G - Frame and Cab

To Next Page

To Previous Page

7-MAINTENANCE

Frameandcab-Lubricate

Lubricatethedoorandwindowhingesevery2000hoursormorefrequentlyifconditionssorequire.

Prioroperation:

Keepallnon-authorizedpersonnelclearofthearea.Parkthemachineonarm,levelsurface,lowerbucket/attach-

menttothegroundandapplytheparkingbrake.

1.Lubricatethedoorandwindowhinges.Usegraphiteto

lubricatethehinges.Donotusegrease.

LEIL16WHL1541AB1

7-117
