Case 621G - Joystick Steering Operation

6-WORKINGOPERATIONS
Joysticksteeringoperation
WARNING
Drivinghazard!
Checkallcontrolsandsafetydevicesinasafe,openareabeforestartingwork.
Failuretocomplycouldresultindeathorseriousinjury.
W0248A
WARNING
Drivinghazard!
Alwaysusetheprimarysteeringwhentravelingonapublicroadorhighway.Theleftarmrestmustbe
raisedandinalockedpositionduringtravel.Donotusejoysticksteeringwhentravelingonapublic
roadorhighway.
Failuretocomplycouldresultindeathorseriousinjury.
W0451A
Joysticksteering(optional)
Thejoysticksteering(JSS)allowstheoperatortosteer
theloaderusingahandcontrolslocatedontheleft-hand
operatorseatarmrest.Thejoysticksteeringallowsfor
steeringmovementattheoperator’sngertips.
MovingtheJSScontrollever(1)rightorleftsteersthe
machineintherightorleftdirection.Whenthejoystickis
released,theJSScontrollever(1)willreturntotheneutral
(center)positionautomaticallywhileleavingthemachine
articulatedinthecurrentposition.
Theuseofthesecontrolsareintendedforshortcycle,
repetitive,highproductionloadandcarryoperationsto
reduceoperatorfatigueandincreaseoperatingefciency.
Thesystemissetupsothatthesteeringwheelisalways
usable(italwayshaspriority).
TheJSSisnotdeactivatedwithsteeringwheeluse.When
thesteeringwheelisused,theJSSnolongerhascontrol.
Assoonasthesteeringwheelisnolongerbeingturned,
theoperatorisabletogobacktousingthejoystickwithout
havingtoreactivateit.
Thejoysticksteeringswitch(2)islocatedonthejoystick
steeringconsole.
Lifttheleft-handarmresttotheverticalpositiontodisable
theJSS.
LEIL16WHL1403AB1
1.Joysticksteering(JSS)controllever
2.Joysticksteering(JSS)switch
6-12
