6-WORKINGOPERATIONS

ACScompatiblecoupler—bucketwithcuttingedge

LEIL16WHL0301AA9

ACScompatiblecoupler—bucketwithteeth

LEIL16WHL0302AA10

NOTE:boltonedgesegmentsbetweenteethavailablefromserviceparts.

6-11
