7-MAINTENANCE

Windshieldwasheruidlevel-Check

Checkthewindshielduidlevelasrequired.Thewind-

shieldwasherreservoirislocatedontheright-handside

ofthemachine,underthesteps.

Ifthewindshielduidlevelistoolow,removetheller

capandaddawindshieldsolutionasrequired.Reinstall

thecap.

NOTE:useprofessionaldetergentuidSC35dilutedwith

waterinrelationtothetemperatureofuse.Witha50–50

solutionofdetergentandwatertheliquiddoesnotfreeze

until-10°C(14°F).Belowthistemperature,usepurede-

tergent.

LEIL15WHL0651AB1
