4-OPERATINGINSTRUCTIONS

AuxiliaryForward,Neutral,Reverse(F-N-R)switch

AuxiliaryF-N-Rswitch(1)foralljoystickandsingleaxis

leverapplications.

F.FORWARD

N.NEUTRAL

R.REVERSE

LEIL16WHL1288AB1

LEIL16WHL1331AA2

LEIL16WHL1303AA3

LEIL16WHL1302AA4

4-21
