4-OPERATINGINSTRUCTIONS

LEIL16WHL1290AA5

ToactuatetheauxiliaryF-N-Rswitch,fulllthefollowing

conditions:

1.Machinestopped

2.Enginerunning

3.AuxiliaryF-N-RSwitch(1)inNEUTRAL(N)

4.TransmissioncontrolleverinNEUTRAL

LEIL16WHL1468AA6

5.Releasetheparkingbrake.

LEIL16WHL1125AA7

4-22
