Case 621G - Page 173

To Next Page

To Previous Page

4-OPERATINGINSTRUCTIONS

Whensteps1through5havebeencompleted,youcan

presstheauxiliaryF-N-Rbuttononkeypadtoactivatethe

auxiliaryF-N-Rswitch.Theindicatorlightofthebutton

willilluminate.

TheauxiliaryF-N-RswitchwillbedeactivatedandF-N-R

controlwilldefaultbacktothestandardtransmission

controlleverif:

1.theengineisstopped;

2.thetransmissioncontrolleveristakenoutoftheNEU-

TRALposition.

LEIL16WHL1125AA8

4-23
