3-CONTROLSANDINSTRUMENTS

Armpad

Adjustthearmpadtoacomfortableheighttooperatethe

loadercontrollevers.

Adjustmentlever

Tolowerthearmpad(1),pullupthelever(2).Adjustthe

armpadtoacomfortableheight.T oraise,pulluponthe

armpad(1).

Adjustmentconsole

Pulluponthehandle(3)andadjustthepositionofthe

console(4)withrespecttotheoperator'sseat,bysliding

itforwardorbackward.

LEIL16WHL1467AB1

3-36
