Case 621G - Operators Seat; Overview

3-CONTROLSANDINSTRUMENTS
Operator'sseat
Overview
WARNING
Lossofcontrolhazard!
DONOTmakeseatadjustmentswhilethemachineisinmotion.Allseatadjustmentshouldbemade
withthemachinestationaryandtheparkingbrakeapplied.
Failuretocomplycouldresultindeathorseriousinjury.
W0293A
Standardoperatorseat–Mechanicalsus-
pension
ConsoleFore/Aftadjustment
Liftupthehandleandadjustthecontrolcarrierequipment
forwardorbackwardasrequired.
LEIL17WHL1484AB1
Weightadjustment
Operatorweightadjustmentrange:50–140kg(about30
knobturns).
Turntheknobcounterclockwisetogototheminimum
weightsettinguntilitstops.Increasetheweightrange
fromthere.
LEIL17WHL1485AB2
SeatFore/Aftadjustment
Pulltheslideadjustmentleverupandadjusttheseatfor-
wardorbackwardasrequired.Releasethelevertolock
theseatinposition.Alwaysmakeadjustmentsfromthe
frontcenteroftheadjustmentbar.
LEIL16WHL1386AB3
3-3
