Case 621G - Exterior Controls; Hood and Timed Disconnect Switches

3-CONTROLSANDINSTRUMENTS
Exteriorcontrols
HoodandTimedDisconnectSwitches
WARNING
Automaticclosure!
Keepyourhandsandbodyandallpersonnelclearofthemachinehoodasitcloses.
Failuretocomplycouldresultindeathorseriousinjury.
W0048A
Hoodswitch
Thehoodswitchislocatedontheleft-handsideofthe
machine.Thehood,left-handandright-handsideengine
coversallowtheaccesstobothenginesides,aircleaner
andcoolers.Alockingmechanismisprovidedforthe
hoodswitchcover.Usethemachinekeytoopenand
closethiscover.
1.Insertthekey.Makesuretocompletelyinsertthekey
forproperoperation.
NOTICE:damagecanoccurtothekeyorlocking
mechanismifkeyisimproperlyinsertedandturned.
2.Afterreleasingthelock,removethekeyandopenthe
cover.
RCPH10WHL425AAH1
3.Thehoodswitchwillautomaticallyraisethehoodon
themachine.Keepalltools,serviceequipment,and
personnelawayfromthehoodwhenitisopeningand
closing.
RCPH10WHL106AAH2
4.Pushupontheswitchtoraisethehood.Theswitch
willremainintheuppositionforhandsfreeopening.
Toclosethehood,pushdownontheswitch.Asa
builtinsafetymeasure,thedowncontrolmustbeheld
inordertolowerthehood.
3-37
