3-CONTROLSANDINSTRUMENTS
Manualhoodopening
WARNING
Crushinghazard!
Thehoodisextremelyheavy.Whenmanuallyraisingthehood,usesuitableblockingequipmentand
watchforsharpedgesonmachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0049B
Ifthemachinehasnopowerorthebatteryis
toolowforthehoodswitchtofunction
NOTICE:donotusethisproceduretostarttheengine.
Jumpstartingtheenginefromthislocationmaycause
electricaland/orharnessdamagetothemachine.
Thismachineisequippedwitha24Vsystem.Use
appropriateboosterbatteryequipment.
1.Useboosterbatterycablestoprovidepower.Connect
thepositiveboostercabletothecabB+junctionpost,
locatedbehindtheright-handsidecabaccessdoor.
2.Connectthenegativecabletoaproperground.The
hoodmaynowbeoperatedattheswitch.
LEIL16WHL1589AB3
Ifthemachinehaspower,buttheactuatoris
notfunctioning
Keepallnon-authorizedpersonnelclearofthearea.
Parkthemachineonrm,levelground,andlowerthe
attachment.Putthetransmissioninneutralandapply
theparkingbrake.Turntheengineoff.
1.Removethetwoactuatormountingboltsattheleft-
handrearofthemachinejustinfrontofthebattery
compartment.
2.Raisethehoodmanuallywithasuitablehoist.Block
forsafety.Donotallowthehoodtoswingoverany
personnel.
LEIL16WHL1126AB4
3-38
