Case 621G - Drive Belt - Replace

7-MAINTENANCE
Drivebelt-Replace
WARNING
Entanglementhazard!
Alwaysstoptheengineandengagetheparkingbrake,unlessotherwiseinstructedinthismanual,
beforecheckingand/oradjustinganydrivebeltorchain.
Failuretocomplycouldresultindeathorseriousinjury.
W0097A
WARNING
Movingparts!
Installallcovers,panels,andguardsafterservicingorcleaningthemachine.Neveroperatethema-
chinewithcovers,panels,orguardsremoved.
Failuretocomplycouldresultindeathorseriousinjury.
W0135A
Replacethedrivebeltevery1000hoursormoreoftenifconditionssorequire.
Prioroperation:
Parkthemachineonarm,levelsurface.Lowertheattachmenttotheground.Applytheparkingbrake,andinstall
thetransportservicelinktopreventunexpectedarticulationmovements.
NOTICE:iftheenginerunswiththedrivebeltloose,thedrivebeltcanslipandcausetheenginetooverheatorthe
batterytoreceiveinsufcientcharge.
1.Opentheenginehoodandlocatethedrivebelt.
