Case 621G - Fuel Tank Sediment - Drain

7-MAINTENANCE
Fueltanksediment-Drain
WARNING
Hotliquidunderpressure!
Fuelinthehighpressurefuellineisstillunderpressureimmediatelyafteryoushutdowntheengine.
Beforeperforminganymaintenanceorinspection,waitfor2minutesafterengineshutdowntoallow
thepressuretodrop.
Failuretocomplycouldresultindeathorseriousinjury.
W0249A
WARNING
Chemicalhazard!
Whenhandlingfuel,lubricants,andotherservicechemicals,followthemanufacturer'sinstructions.
WearPersonalProtectiveEquipment(PPE)asinstructed.Donotsmokeoruseopename.Collect
uidsinpropercontainers.Obeyalllocalandenvironmentalregulationswhendisposingofchemi-
cals.
Failuretocomplycouldresultindeathorseriousinjury.
W0371A
Draincondensationfromthefueltankevery500hoursofoperationormorefrequentlyifconditionssorequire.
Prioroperation:
Keepallnon-authorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparking
brakeappliedandtheattachmentloweredtotheground.Installthetransport/servicelinkintothelockedposition.
1.Locatethedrainplugandhandleareonthebottom
left-handfrontcornerofthefueltank,behindtherear
axle.
2.Haveasuitablecontainerreadytocollecttheconden-
sationandfuel.Disposeofthewastefollowinglocal
regulations.
3.Openthefueltankdrainslowly,removethetankdrain
plug,andallowthecondensationtoowuntilonlyfuel
isdischarged.
4.Turnthedrainhandleandclosethedrain.Replacethe
tankdrainplug.
RCPH10WHL075BAL1
7-83
