7-MAINTENANCE

DEF/AdBlue®tankventlter-Replace

ReplacetheDEF/ADBLUE®tankventlterevery500hoursthereafterormorefrequentlywhenoperatingconditions

aresevere.

1.Lowerthebucket/attachmenttothegroundandinstall

thetransport/servicelinkintothelockedposition.

LEIL16WHL0048AB1

2.Opentheenginecompartment.TheDEF/ADBLUE®

tankventlterislocatedontheright-handsideofthe

machineandisattachedtothemufersupport.

LEIL14WHL0015AA2

3.Loosentheclampsfromthebreatherbodyandremove

fromthehose.

4.Discardappropriatelyandreinstallanewlter.

LEIL14WHL0015AA3

7-91
