6-WORKINGOPERATIONS

Joysticksteeringarmrestadjustment

Theleft-handarmrestequippedwithoptionaljoystick

steeringcontrolscanbeadjustedforoperatorcomfort.

Toadjusttheheightofthearmrest,usethelever(1).

Lowerorraisethearmrestintothedesiredposition.

Fortiltadjustment,loosentheknob(2),thentiltthearm-

restintothedesiredposition.Retightentheknob(2)once

theadjustmentiscomplete.

LEIL16WHL1405AB2

Standardoperatorseat

LEIL16WHL1404AB3

Premiumoperatorseat

6-13
