2-SAFETYINFORMATION

Moveawayfromme

Wavehandsbackandforth(palmsoutward).

LEEN11T0008AA4

Gothisfar

LEEN11T0009AA5

Allstopandhold

LEEN11T0010AA6

Stop

Moveonehandbackandforth.

LEEN11T0011AA7

2-18
