3-CONTROLSANDINSTRUMENTS

Joysticksteeringarmrestinstallation

Thejoysticksteeringarmrest(1)isinstalledattheleft-

handsideoftheoperatorseat.

Standardoperatorseat(mechanicalsuspension)

Optionaloperatorseat(airsuspension,heated)

LEIL16WHL1436AA2

Optionalpremiumoperatorseat(airsuspension,heated)

LEIL16WHL1437AA3

3-18
