1-GENERALINFORMATION

Enginemakeandmodel

Engineserialnumber

Theidenticationplatesoftheengine(1)and(2)arelo-

catedontheengineoilpan.

Thehomologationplate(1)shows:

•Serialnumber

•Enginetype

Theidenticationplate(2)shows:

•Serialnumber

•Manufacturingdate

•CNHpartnumber

•FPTpartnumber

LEIL19WHL0558AB3

Transmission

Theserialnumberplateisonthetransmissionfaceplate.

LEIL16WHL0083AA4

Axle

Theserialnumberplateisontheaxlecrossmember.

RCPH10WHL081AAH5

1-10
