Case 621G - Page 188

To Next Page

To Previous Page

5-TRANSPORTOPERATIONS

Transportingthemachinebyrailorship

Transportbyrailorshipissubjecttospecicregulation.Consultanapprovedorganization.

Liftingthemachine

LEIL16WHL1135FA5

Liftinghooks

Alwaysplacethearticulationtransportservicelinkinthelockedpositionpriortolifting.Liftthewheel

loaderusingthefourliftingattachmentpointsidentiedonthemachinebythelifthooksymbol.Orient

theliftingaccessoriesinaverticalpositionasshowninthegureabove.

5-4
