7-MAINTENANCE

Glossary

Acronym

Denition

DEF

DEF/ADBLUE®

ISOInternationalOrganizationforStandardization

MSDSMaterialSafetyDataSheet

NOxNitrogenOxide

PPEPersonalProtectiveEquipment

SCRSelectiveCatalyticReduction

ULSDUltraLowSulfurDiesel

SMSupplyModule

DOCDieselOxidationCatalyst

CUCCleanUpCatalyst

Unitsofmeasure

SymbolDenition

CCentigrade

FFahrenheit

Degree

Percent

Lessthan

Greaterthan

mg/kg

Milligramsperkilogram

7-36
