7-MAINTENANCE

Afterstartingtheengine

•

Didtheenginestartcorrectly?Aretheexhaust

fumesnormal?Anystrangenoises?

•

Checkforabnormalnoiseonthehydrauliccompo-

nents.

•

Checkforwater,fuel,oroilleaksonthecomponents.

•

Checktheaudiblealarmdevices,workinglightsand

windshieldwipers.

•

Checkthatallhydrauliccircuitsarefunctioningcor-

rectly.

Accessdoorsandlllocations

1.Enginehood–right-handside

Fuelll,oilll,DEF/ADBLUE®ll

LEIL14WHL0011AB1

2.Batteryaccess–left-handside

LEIL15WHL0076AA2

3.Enginehood–left-handside

Timeddisconnectswitch,airlter,transmissionoil

cooler

LEIL13WHL0304AA3

7-40
