Case 621G - Page 263

To Next Page

To Previous Page

7-MAINTENANCE

6.FilltheenginewiththeproperamountofCASE

AKCELAUNITEKNO.1™SBLCJ-4throughthell

port(2).

7.Starttheengineandrunatidlespeed.Checktheen-

gineoillterandremotedrainforleaks.

8.Aftertwominutesstoptheengine.

9.Waitfortheengineoiltodraindownforanaccurate

readingonthedipstick.

10.Checkthedipstick(1)andaddadditionalCASE

AKCELAUNITEKNO.1™SBLCJ-4,ifnecessary.

11.Re-installtheremotedraincover.

12.Securetheenginehood.

RCPH10WHL899AAH4

7-55
