Case 621G - Page 283

7-MAINTENANCE
2.T oreplacethedrivebelt,removethefourscrewsthat
holdtheprotectivecoverinplace.
LEIL16WHL0585AA2
LEIL16WHL0586AA3
3.Usea3/8inchbreakerbartoactuatethebelttensioner
justenoughtoreleasethetensiononthedrivebelt.
Removethedrivebelt.
LEIL16WHL0587AA4
4.Placethedrivebeltaroundthepulleysofthecrank-
shaft,thefanandthealternator.
5.Raisethebelttensionerandinstallthedrivebeltover
thewaterpumppulley.
NOTE:thewaterpumppulleyhasthesmallestange,
whichallowsaneasilyinstallationofthedrivebelt.
6.Lowerthetensioner.
7.Inspectallthepulleystocheckifthebeltisinthecorrect
position.
8.Starttheengineandrunatlowidlefor60–90s.
9.Stoptheengine.
10.Inspectthetensionerforacorrectdrivebeltalignment.
NOTE:theminimumclearancefromthefrontortherear
angeofthepulleytothebeltis1mm.
7-75
