7-MAINTENANCE

4.Extractthemainlterelement(1)fromthelterhousing

(2).

LEIL15WHL0567AB4

5.Discardthemainlterelement.

6.Wipetheinsideofthelterhousing.

7.Installanewmainlterelementintothelterhousing.

8.Securetheltergridassemblytothelterhousing.

9.Closetheright-handdoor.

7-102
