7-MAINTENANCE

8.Marklocationofpickupunitwithintankbeforeremoval.

TwisttheunitoftheDEF/ADBLUE®level/temperature

sensorcounterclockwisetoloosenitfromtank.

RCPH11WHL707BAU8

9.LifttheunitoftheDEF/ADBLUE®level/temperature

sensoroutoftank.Cleanthesuctionlterbyrinsing

withwater.Replaceifdamage.

LEIL13WHL0235BA9

10.ReinstalltheDEF/ADBLUE®level/temperatureonthe

DEF/ADBLUE®tank.

11.Filltheenginecoolingsystem.

7-124
