Case 621G - Page 374

8-SPECIFICATIONS
621GCylinderSpecications
Liftcylinder
Borediameter
120.6mm(4.75in)
Roddiameter
63.5mm(2.50in)
Stroke787.6mm(31.01in)
Steercylinder
Borediameter
76.2mm(3.00in)
Roddiameter
44.5mm(1.75in)
Stroke484.9mm(19.09in)
DumpcylinderZ-BarandXRXT
Borediameter
127.0mm(5.00in)114.0mm(4.50in)
Roddiameter
76.2mm(3.00in)63.5mm(2.50in)
Stroke619.7mm(24.40in)819.9mm(32.60in)
InstrumentationGauges
SpeedometerEngineCoolantTemperature(ECT)Gearposition
TachometerHydraulicoiltemperatureTransmissionmodes
HourmeterTransmissionoiltemperature
Travelselected(FNR)
Fuellevel
DEF/ADBLUE®level
Workmode
OperatorEnvironment
ROPScabwithheater
KeystartArticulatedpowersteeringwithtilt
Adjustablesuspensionseat
Singlelever2-spoolloadercontrolCupholder
Coathook
Interiorrearviewmirror
Singlebrakepedal
StoragetrayStoragebox
Domelight
Exteriorrearviewmirrors
Front(intermittent)andrearwipers
Frontandrearwindshieldwashers
Rightandleftsteps/platforms52mm(2in)retractableseatbelt
HydraulicSpecications
HydraulicsystemAvariabledisplacementpistonpumpisusedtosupply
oiltointegratedloaderandsteeringhydraulicsystem.
Pumpdisplacement90cm³/rev(5.49in³/rev)
171l/min@2000RPM
(45.2USgpm@2000RPM)
SteeringCenterpivotarticulatedsteering—frontandrearwheels
alwaystrack.Twohydrauliccylinderscontrolledbya
hydrostaticsteeringgearandapriorityvalve.
Filtration
10-micron,fullowreplaceablecartridgesonreturnline,
conditionindicatorlightforlter
8-4
