Case 621G - Page 380

8-SPECIFICATIONS
621GLoader–LiftArmsSpecications
LEIL16WHL0629FB1
621GZ-BarSpecications-1.9m³(2.5yd³)Blade/1.8m³(2.4yd³)Teeth‐ ‐
‐
PinOn
BucketwithBolt-onEdgeBucketwithteeth
ISOBucketSpecications
Capacity(heaped)1.91m³(2.50yd³)1.83m³(2.40yd³)
Bucketwidth(maximumouter)2602mm(102.4in)2593mm(102.1in)
DimensionalOutlineSpecications
A(topofcabheight)3385mm(133.3in)3385mm(133.3in)
B(wheelbase)2900mm(114.2in)2900mm(114.2in)
C(groundclearance)389mm(15.3in)389mm(15.3in)
D(rearangleofdeparture)25°25°
Overallwidthw/obucket2478mm(97.6in)2478mm(97.6in)
Centerlinetreadwidth1950mm(76.8in)1950mm(76.8in)
Turningradius(outsideoftires)5223mm(205.6in)5223mm(205.6in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)4941mm(194.5in)4941mm(194.5in)
F(hingepin-fullyraised)3833mm(150.9in)3834mm(150.9in)
G(overall-bucketlevelonground)7237mm(284.9in)7382mm(290.6in)
H(dump-fullyraised,45°dump)2899mm(114.1in)2805mm(110.4in)
J(reach-fullyraised,45°dump)916mm(36.0in)1021mm(40.2in)
K(reach-2.13m(7.0ft),45°dump)1466mm(57.7in)1525mm(60.0in)
L(digdepth)72mm(2.8in)76mm(3.0in)
ISOLoadSpecications
OperatingWeight(withoutload)12743kg(28093lb)12707kg(28013lb)
Operatingload4400kg(9700lb)4456kg(9824lb)
Tippingload
Machinestraight
40°turn
10378kg(22881lb)
8800kg(19401lb)
10503kg(23155lb)
8912kg(19648lb)
8-10
