Case 621G - Page 402

8-SPECIFICATIONS
721GLoader-LiftArmsSpecications
LEIL16WHL0629FB23
721GZ-BarSpecications-2.3m³(3.0yd³)Blade/2.1m³(2.8yd³)Teeth‐ ‐
‐
PinOn
BucketwithBolt-onEdgeBucketwithteeth
ISOBucketSpecications
Capacity(heaped)2.29m³(3.00yd³)2.14m³(2.80yd³)
Bucketwidth(maximumouter)2700mm(106.3in)2713mm(106.8in)
DimensionalOutlineSpecications
A(topofcabheight)3379mm(133.0in)3379mm(133.0in)
B(wheelbase)3253mm(128.1in)3253mm(128.1in)
C(groundclearance)384mm(15.1in)384mm(15.1in)
D(rearangleofdeparture)29°29°
Overallwidthw/obucket2558mm(100.7in)2558mm(100.7in)
Centerlinetreadwidth2030mm(79.9in)2030mm(79.9in)
Turningradius(outsideoftires)5748mm(226.3in)5748mm(226.3in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)5165mm(203.4in)5165mm(203.4in)
F(hingepin-fullyraised)3976mm(156.5in)3976mm(156.5in)
G(overall-bucketlevelonground)7606mm(299.4in)7753mm(305.2in)
H(dump-fullyraised,45°dump)2962mm(116.6in)2868mm(112.9in)
J(reach-fullyraised,45°dump)1081mm(42.6in)1196mm(47.1in)
K(reach-2.13m(7.0ft),45°dump)1628mm(64.1in)1700mm(66.9in)
L(digdepth)77mm(3.0in)75mm(3.0in)
ISOLoadSpecications
OperatingWeight(withoutload)14698kg(32403lb)14652kg(32301lb)
Operatingload4705kg(10373lb)4804kg(10592lb)
Tippingload
Machinestraight
40°turn
11562kg(25490lb)
9410kg(20745lb)
11796kg(26005lb)
9609kg(21183lb)
8-32
