9-ACCESSORIES

Auxiliarypoweroutlets

Theauxiliarypoweroutletscanbeusedfortheconnection

oflightingdevicestohelpwithserviceandmaintenance

proceduresorotherpurposes.Themachineisequipped

withtwoauxiliarypoweroutlets:

1.one24Vsocketlocatedintheleft-handcornerofthe

operator’scompartment(thiscanbeusedtoplugin

theoptionalcigarlighterorchargingphones,etc.);

LEIL16WHL1277AB10

2.one12Vsocketlocatedintheright-handconsole.

LEIL16WHL1284AB11

Coathooks

Thetwocoathooksarelocatedintheoperator’scompart-

ment,ontheright-handandleft-handBpillars.

LEIL17WHL1575AB12

9-4
