3-CONTROLSANDINSTRUMENTS

Optionaloperatorseat–Airsuspension,

heatedseat

ConsoleFore/Aftadjustment

Liftupthehandleandadjustthecontrolcarrierequipment

forwardorbackwardasrequired.

LEIL17WHL1486AB9

Weightadjustment

Usethelevertoincreaseordecreasetheweightresis-

tance.Adjusttheseatforoperatorpreferenceandcom-

fort.

LEIL16WHL1409AB10

SeatFore/Aftadjustment

Pulltheslideadjustmentleverupandadjusttheseatfor-

wardorbackwardasrequired.Releasethelevertolock

theseatinposition.Alwaysmakeadjustmentsfromthe

frontcenteroftheadjustmentbar.

LEIL16WHL1408AB11

Variabledamperadjustment

Usetheknobtoadjustthedampingforcesforoperator

ridepreference.

LEIL16WHL1425AB12

3-6
