3-CONTROLSANDINSTRUMENTS

Seatdepthadjustment

Lifthandleupandmovethecushiontothedesiredposi-

tion.Releasethehandletolockthecushioninplace.

LEIL17WHL1488AB22

Seatcushionangleadjustment

Liftuponthehandleandmovetheseattothedesired

angle.Releasethehandletolockthecushionangle.

LEIL17WHL1489AB23

Backrestadjustment

Liftupthehandleandmovethebackresttothedesired

position.Releasethehandletolockinposition.

LEIL16WHL1399AB24

Armrestangleadjustment

Turntheknobtoraiseorlowerthearmresttothedesired

position.

LEIL16WHL1400AB25

3-10
