3-CONTROLSANDINSTRUMENTS

5.Cupholder

Acupholderislocatedattherearpartoftheright-hand

console.Thisareacanalsobeusedtoaccommodatethe

optionalashtray.

LEIL16WHL1279AB5

6.USBandAUXports

USBandAUXportsarelocatedinthelowerpartofthe

right-handconsole.

LEIL16WHL1283AB6

7.Poweroutletsocket12V

A12VpoweroutletsocketislocatednexttotheUSBand

AUXportsinthelowerpartoftheright-handconsole.

LEIL16WHL1284AB7

8.Horn

Presstheswitchtoactivatethehorn.

LEIL16WHL1282AB8

3-22
