OPERATING THE MACHINE
3-45
lowering in the front and
in the back
push the left hydraulic
control lever forward
(without switches A, B, C
and D all stabilizers lower
at the same time)
lowering in the front
and in the back
- front right stabilizer:
activate button (A)
- front left stabilizer:
activate button (B)
- rear right stabilizer:
activate button (C)
and/or
- rear left stabilizer:
- activate button (D)
and push forward the
left hydraulic control
lever
lifting in the front and in
the back
push the left hydraulic
control lever backward
(without switches A, B, C
and D all stabilizers lift at
the same time)
lifting in the front and
in the back
- front right stabilizer:
activate button (A)
- front left stabilizer:
activate button (B)
- rear right stabilizer:
activate button (C)
- rear left stabilizer:
activate button (D)
and pull backward the
left hydraulic control
lever
