Case WX145 - Engine Oil - Change

SECTION 4
4-50
ENGINE OIL - CHANGE
DRAINING HOSE FOR OIL CHANGE
The engine is equipped with a special filler neck (1)
for oil discharge.
In this way the oil change can be performed in a
clean and not polluting way.
Perform the oil change in this way:
- place under the drain sleeve a collecting container
for old oil;
- take from the equipment available the relevant
draining hose;
- unscrew the blanking plug (3) from the oil drain
sleeve (1);
- screw up the hose (2). The sleeve (1) opens auto-
matically and oil is discharged;
- once oil has been drained, unscrew the hose (2).
The drain sleeve (1) closes independently;
- retighten the protection cover (3).
OIL DRAINING
Bring engine oil to operating temperature.
Park the machine on a level surface, and secure it
against inadvertent movements.
Shut off the engine.
Disassemble the base-plate for maintenance below
the engine compartment. Now the oil drain sleeve
(1) is accessible.
Drain the engine oil through the drain sleeve. For
this operation, use the proper hose.
S WARNING S
Risk of burns caused from hot engine oil.
Collect escaping oil and discard without polluting
the environment.
