SECTION 2
2-40
VENTILATION, HEATING AND AIR CONDITIONING (OPTIONAL)
VENTILATION (air from outside)
WITH ENGINE RUNNING
Use handle (1) to activate and to adjust the blower
speed.
WITH ENGINE SHUT OFF
Turn first of all the ignition key (2) to position “I”.
Now it is possible to activate the knob (1).
By means of rotary knob or selector (3) you can set
the air warmth intensity.
Defrosting the front, side and rear windows
Start the engine. Full heating output is attained only
when the engine is at operating temperature.
Close the air-flow vents (4) under the operator’s
seat.
44
45
S WARNING S
Windows that are steamed or iced up obstruct the
operator’s view of the hazard zone.
Never move the machine until the windows are
defrosted and the hazard zone can be clearly seen.
46
