ELECTRICAL SYSTEM
Service voltage ........................................................................................................................................... 24 V
Batteries................................................................................................................................................ 2 x 12 V
Batteries rating........................................................................................................................................ 100 Ah
Alternator .................................................................................................................................................... 70 A
Starter motor ......................................................................................................................... 4 kW (2963 ft·lb/s)
BUCKETS
BUCKETS - WX 145
BUCKETS - WX 165
BUCKETS - WX 185
NOTE: for the other available bucket models
address to Dealer.
SAE capacity (m
3
) (ft
3
) Heaped capacity (m
3
) (ft
3
)
Width (mm) (in) Weight (kg) (lb)
0.22 (7.76) 0.16 (5.65) 450 (17.71) 300 (640)
0.32 (11.30) 0.28 (9.88) 600 (23.62) 330 (726)
0.43 (15.18) 0.36 (12.71) 750 (29.52) 370 (814)
0.54 (19.06) 0.46 (16.24) 900 (35.43) 410 (902)
0.62 (21.89) 0.52 (18.36) 1000 (39.37) 440 (968)
0.70 (24.72) 0.58 (20.48) 1100 (43.30) 470 (1034)
0.77 (27.19) 0.65 (22.95) 1200 (47.24) 490 (1078)
SAE capacity (m
3
) (ft
3
) Heaped capacity (m
3
) (ft
3
)
Width (mm) (in) Weight (kg) (lb)
0.27 (9.53) 0.25 (8.82) 500 (19.68) 350 (770)
0.39 (13.77) 0.35 (12.36) 600 (23.62) 385 (847)
0.57 (20.12) 0.51 (18.01) 800 (31.49) 455 (1001)
0.66 (23.30) 0.60 (21.18) 900 (35.43) 495 (1089)
0.75 (26.48) 0.65 (22.95) 1000 (39.37) 525 (1155)
0.85 (30.01) 0.75 (26.48) 1100 (43.30) 550 (1210)
0.95 (33.54) 0.83 (29.31) 1200 (47.24) 590 (1298)
SAE capacity (m
3
) (ft
3
) Heaped capacity (m
3
) (ft
3
)
Width (mm) (in) Weight (kg) (lb)
0.27 (9.53) 0.25 (8.82) 500 (19.68) 350 (770)
0.38 (13.41) 0.34 (12) 600 (23.62) 380 (847)
0.50 (17.65) 0.43 (15.18) 750 (29.52) 440 (968)
0.66 (23.30) 0.51 (18.01) 900 (35.43) 495 (1089)
0.75 (26.48) 0.64 (22.60) 1000 (39.37) 525 (1155)
0.85 (30.01) 0.74 (26.13) 1100 (43.30) 550 (1210)
0.95 (33.54) 0.81 (28.60) 1200 (47.24) 590 (1298)
