Case WX145 - Travelling on Public Roads

SECTION 1
1-12
TRAVELLING ON PUBLIC ROADS
Transfer on public roads (each time you leave a yard)
is allowed only with an approved configuration, com-
plying with dimensions (A), (B) as shown on the tables.
S WARNING S
Road circulation (on public roads) is ruled by special pro-
visions varying from country to country. Check before-
hand with local authorities for circulation provisions.
WX 145
MONOBOOM
Dipper
mm
(in)
2600
(102.36)
2300
(90.55)
2000
(78.73)
A Maximum height
mm
(in)
3930
(154.72)
3870
(152.36)
3915
(154.13)
B Frontal off-set
mm
(in)
4080
(160.62)
4095
(161.22)
4080
(160.62)
PLACING BOOM
Dipper
mm
(in)
2600
(102.36)
2300
(90.55)
2000
(78.73)
A Maximum height
mm
(in)
4000
(157.48)
3955
(155.70)
3950
(155.51)
B Frontal off-set
mm
(in)
2685
(105.70)
2750
(108.26)
2910
(114.56)
OFF-SET BOOM
Dipper
mm
(in)
2000
(78.73)
A Maximum height
mm
(in)
4000
(157.48)
B Frontal off-set
mm
(in)
4130
(162.59)
WX 165
MONOBOOM
Dipper
mm
(in)
2900
(114.17)
2600
(102.36)
2300
(90.55)
A Maximum height
mm
(in)
3980
(156.69)
3965
(156.10)
3965
(156.10)
B Frontal off-set
mm
(in)
4200
(165.35)
4215
(165.94)
4225
(166.33)
PLACING BOOM
Dipper
mm
(in)
2600
(102.36)
2300
(90.55)
-
A Maximum height
mm
(in)
3925
(154.52)
3925
(154.52)
-
B Frontal off-set
mm
(in)
2605
(102.55)
2680
(105.51)
-
OFF-SET BOOM
Dipper
mm
(in)
2000
(78.73)
A Maximum height
mm
(in)
4000
(157.48)
B Frontal off-set
mm
(in)
4130
(162.59)
