Case WX145 - Page 26

INTRODUCTION, SAFETY, PLATES AND DECALS
1-13
WX 185
MONOBOOM
Dipper
mm
(in)
2800
(110.24)
2400
(94.98)
2000
(78.73)
A Maximum height
mm
(in)
3850
(151.57)
3800
(149.60)
3800
(149.60)
B Frontal off-set
mm
(in)
4750
(187.00)
4750
(187.00)
4850
(190.94)
PLACING BOOM
Dipper
mm
(in)
2400
(94.98)
2000
(78.73)
-
A Maximum height
mm
(in)
4000
(157.48)
4000
(157.48)
-
B Frontal off-set
mm
(in)
2800
(110.24)
2750
(108.26)
-
S WARNING S
During road transfer with monoboom version the
help of a flagman to signal the motion is compul-
sory.
Car with blinking lights and flags should precede
and follow the machine.
S WARNING S
ITALY ROAD TRAVEL APPROVAL: travel with
traffic beams and rotary light alight (also during the
day). If the machine is equipped with off-set boom,
it is not approved for road travel.
GERMANY ROAD TRAVEL APPROVAL: travel
with traffic beams alight (also during the day). If the
machine is equipped with off-set boom, it is not
approved for road travel.
S WARNING S
If the machine is equipped with off-set boom, to
travel on public highways, address each time the
pertinent authorities and respect the rules in force
relevant to circulation.
