Case WX145 - Outfit with Placing Boom; Dipper AB; G = Tyres Maximum Width O = Machine Maximum Width; Dipper (MM) (In)

SECTION 8
8-4
WX 165 MODELS
OUTFIT WITH PLACING BOOM
G = tyres maximum width
O = machine maximum width
mm (in)
Dipper A B C D E F G H I L M N O P Q R S T
2300
(90.55)
2550
(100.39)
450
(17.71)
1230
(48.42)
2000
(78.73)
320
(12.59)
2886
(113.62)
2520
(99.21)
3040
(119.68)
3900
(153.54)
365
(14.37)
4803
(189.09)
930
(36.61)
2500
(98.42)
1070
(42.12)
8283
(326.10)
8423
(331.61)
1175
(46.25)
1010
(39.76)
2600
(102.36)
2550
(100.39)
450
(17.71)
1230
(48.42)
2000
(78.73)
320
(12.59)
2950
(116.14)
2520
(99.21)
3040
(119.68)
3900
(153.54)
365
(14.37)
4814
(189.52)
930
(36.61)
2500
(98.42)
1070
(42.12)
2894
(113.93)
8434
(332.04)
1175
(46.25)
1010
(39.76)
2900
(114.17)
2550
(100.39)
450
(17.71)
1230
(48.42)
2000
(78.73)
320
(12.59)
3022
(118.97)
2520
(99.21)
3040
(119.68)
3900
(153.54)
365
(14.37)
4795
(188.77)
930
(36.61)
2500
(98.42)
1070
(42.12)
8275
(325.78)
8415
(331.29)
1175
(46.25)
1010
(39.76)
Dipper (mm) (in)
Rear blade
(kg) (lb)
Rear stabilizers
(kg) (lb)
Front blade and
rear stabilizers
(kg) (lb)
Front and rear
stabilizers (kg) (lb)
2300 (90.55) 16970 (37334) 17480 (38456) 17900 (39380) 18400 (40480)
2600 (102.36) 17010 (37422) 17520 (38544) 17940 (39468) 18440 (40568)
2900 (114.17) 17060 (37532) 17570 (38654) 17990 (39578) 18490 (40678)
