DATA AND TECHNICAL SPECIFICATIONS

8-27

TIGHTENING TORQUES

CENTRALIZED LUBRICATION PUMP (OPTIONAL)

Service temperature..................................................................................... - 40 °C at 70 °C (-40 °F at 158 °F)

Allowable service pressure ................................................................................................... 350 bar (5074 psi)

Flow rate: ......................................................................................................................................... 2 l (0.5 gal)

Service voltage ........................................................................................................................................... 24 V

Maximum current consumption..................................................................................................................... 3 A

Revolutions ........................................................................................................................................ at 17 rpm

Delivery ................................................................................................................... 2.8 cm

/min. (0.17 in

/min.)

Set working time ........................................................................................................................................6 min

Down-time set ............................................................................................................................................... 3 h

FUEL SYSTEM

WX 145 WX 165 WX 185

Wheels nuts M22 Nm (lbf·ft) 450 (331.90)

Slewing bearing M16 Nm (lbf·ft) 270 (199.14) 280 (206.52)

Engine supports

M12 Nm (lbf·ft) 104 (76.71) 60 (44.25)

M16 Nm (lbf·ft) 270 (199.14) 105 (77.44)

M20 Nm (lbf·ft) 490 (361.40) 250 (184.39)

Slewing gearbox M16 Nm (lbf·ft) 270(199.14) 250 (184.39)

Counterweight M30 Nm (lbf·ft) 2250 (1659.51)

Axles M20 Nm (lbf·ft) 520 (383.53)

WX 145 WX 165 WX 185
