SECTION 3
3-26
BEFORE BEGINNING THE WORK
Every day, before setting the machine in operation,
carry out daily maintenance.
Enter the cab and seat on the operator’s seat.
Carry out all start-up operations.
With engine at service temperature, set the required
rpm by means off push-button (1). According to the
operation mode, it is possible to set up to 7 stages
the rpm/power ratings.
MACHINE IN WORKING POSITION
Return the machine to basic position. Work possibly
in this position to achieve the maximum balance.
Stop the machine.
Engage the parking brake by pressing the button
(2).
Lower the stabilizers.
The machine can be installed with different stabiliz-
ers configurations.
Working mode Power levels
Craning 1 - 3
Digging 4 - 7
Levelling 4 - 7
Road travel DRIVE
Hammer 4 - 7
Shears 1 - 7
Rotary cutter 4 - 7
