ATTACHMENTS
7-35
ROTARY LIGHT
SINGLE LIGHT
Rotary lights are fitted on a mounting stud and
secured with a retaining screw. The electrical con-
nection is incorporated in the stud. In this way a
connecting cable is not required.
DOUBLE LIGHT
In some countries, two rotary lights are mandatory.
1st rotary light: installed as described for the single
light.
2nd rotary light: this second rotary light is attached
by means of a magnetic base (electrical connection
via coupling) or it is installed as the 1st light.
SWITCHING ON AND OFF
SWITCHING ON THE ROTARY LIGHT/LIGHTS
Connect switch (1).
Depress switch face without symbol, the lamp goes
out.
SWITCHING OFF THE ROTARY LIGHT/LIGHTS
Disconnect switch (1).
Depress switch face with symbol, the lamp goes
out.
S WARNING S
The rear floodlamps can only be switched on, if the
ignition key is set to position “I” (ignition ON).
60
